RPTFE is a multi-composite material, the proportion of components can be adjusted according to the actual working conditions of customers, not fixed. The products are mainly used for piston rings, oil-free gas pump bowls, bushings, shaft tiles, sealing gaskets and other parts.
High-Temperature Resistance: Can withstand long-term use at temperatures up to 290°C and short-term use at temperatures up to 480°C. Wear Resistance: Under non-lubricated conditions, the PV critical value is more than 10 times that of general engineering plastics, capable of withstanding strong vibration wear and impact wear.
Heat Deformation Resistance: Does not melt or soften at high temperatures and can withstand high loads.
Insulation: Insulation strength exceeds 20 kV/mm.
Chemical Resistance: Resistant to lubricating oils and solvents.
Resistant to plasma and radiation.
Excellent machinability.
Item | PI filled PTFE |
Color | Orange |
Density g/cm3 | 2 |
Shore hardness D | 65, and mineral water bottle cap (HDPE) equivalent |
Insulation | Non-conductive |
Chemical Propertie | Not resistant to alkali and hot concentrated acid, nor hydrolysis, etc. |
Tensile strength/MPa | 15.5 |
Elongation at break/% | 290 |
Coefficient of friction | 0.2 |
Wear rate | 3.0×10-6mm3(N.m)-1 |
Friction and wear test conditions | Room temperature 23℃, GCr15 steel for wear parts, rotational speed 200r/min (line speed 0.43m/s), load 200N, time 120min. |
